LITTEL-JAX 2- AND 3- CONDUCTOR

94

JACKS AND PLUGS

?

PHONE: 773 792-2700

* Please visit the product pages on our website for the most up-to-date product information

1/4" PHONE JACKS

PREFIX OPTIONS

Blank- 1/4" Commercial Jack

SERIES

1-Littel Jax ?

CIRCUITRY

1- I

14B

PC-12A

C-

FA-

FAL-

Accepts Mill Plug

.205" Faston Terminals

.205" Faston Terminals

2A- III

2B- IV

3- V

and .375" Long Bushing

L-

PC-

S-

.375" Long Bushing

PC Terminals

Accepts .206 Diameter Plugs

3A-

3B-

3E-

4B-

VI

VII

IX

XII

TWO CONDUCTOR PART NUMBERS

FAL-11

.205 FASTON

TERMINAL

11

Part

Number

Description

Jack

Schematic 1

Typical

Mating

Plug

LITTEL-JAX ? COMMERCIAL PHONE JACKS

2- AND 3-CONDUCTOR

Littel-Jax phone jacks mate with standard commercial phone

plugs and are available with .25" and .21" inside diameter

bushings.

MIL LITTEL-JAX ? PHONE JACKS

2- AND 3-CONDUCTOR MIL-SPEC, MIL-J-641 (E)

MIL jacks mate with MIL-type phone plugs with .25" (6.35mm)

or .21" (5.34mm) diameter bushings. Numbers C11 and C12B

have a non-turn locating pin which keys the jack to the

mounting surface. For low contact resistance applications,

jack number C12A has fine silver contacts on shunts and

tip springs.

11

C11

FA11

FAL11

L11

12A

C12A

L12A

PC12A

13

13A

13E

Open circuit

MIL Number M641/6-1

.205 inch FASTON terminal

.375 inch long bushing

.205 FASTON terminal

.375 inch long bushing

Tip shunt

MILNumber M641/12-1

.375 inch long bushing

PC board mount

Isolated “make” circuit

Transfer circuit

Isolated “break” circuit

I

I

I

I

I

III

III

III

III

V

VI

IX

250

440

250

250

250

250

440

250

250

250

250

250

MOUNTING

Chassis/Panel: See Mounting Data drawing below;

THREE CONDUCTOR PART NUMBERS

smallhole is required only for jacks numbers C11 and C12B

with non-turn locating pin.

Maximum Panel Thickness: .156" (4mm) for standard

.276" (7mm) long bushing; .25" (6.35mm) for .375" (9.5mm)

long bushing.

NOTE: For panels thicker than .25" see Thick Panel Phone Jax.

Insulated Mount: See drawing. S1028 flatwasher and

Part Number S1029 shoulder washer must be ordered

12B

L12B

C12B

13B

14B

Double open circuit

.375 inch long bushing

MIL number M641/5-1,

.250 inch inside diameter

Tip shunt

Double closed circuit

IV

IV

IV

VII

XII

267

267

480

267

267

separately for mounting in .437" diameter hole.

NOTE: See Hi-D Jax ? for jack specifically designed for

insulated mounting without additional washers.

PART NUMBERS

(.210" INSIDE DIAMETER BUSHING)

PC Board Mounting: See Recommended PC Board Layout

drawing below for jacks with PC terminals. Recommended

PC board thickness is .062".

Mounting Centers: 1.188" (30mm) recommended. Centers

may vary with jack selected, for example, Number

S11

S12A

S12B

S13B

2

2

3

3

conductor

conductor

conductor

conductor

I

III

IV

VII

S250

S250

S267

S267

11 mounts on .813" (20.6mm) and 14B mounts on

1.125" (28.6mm) minimum centers.

STEREO JACK

CONNECTIONS

1. Refer to jack schematics on pages 79 and 80. Other circuits are available;

contact factory.

DIMENSIONS ARE FOR REFERENCE ONLY

www.switchcraft.com

Inch

(mm)

? Registered trademark of Switchcraft, Inc.

Note: Contact your Switchcraft Representative for price and delivery
